IN MOTION DMC 50720P-AC EXT 24 9032 0120 49 – Advanced Motion Control Module

Product Overview

The DMC 50720P-AC EXT 24 is a high-performance motion control module designed for industrial automation, robotics, and precision machinery applications. It provides precise positioning, velocity control, and torque regulation for AC servo motors, stepper motors, and hybrid systems. Built for robust operation in demanding environments, the module supports both standalone and networked operation with seamless integration into automated production lines.

Key Features

Advanced Motion Control: Supports point-to-point, linear, circular, and interpolation movements.
AC Servo Compatibility: Works with a wide range of AC servo motors with encoder feedback.
High-Speed Communication: Compatible with Ethernet, CANopen, and Modbus protocols.
Extended Inputs/Outputs: Multiple digital and analog I/Os for sensors, actuators, and safety interlocks.
Programmable Motion Profiles: Customizable acceleration, deceleration, and velocity ramps.
Robust Protection: Overcurrent, overvoltage, thermal, and motor stall protections included.
User Interface: LCD display and LED indicators for status, errors, and diagnostics.
Data Logging: Stores operational events and performance metrics for maintenance and troubleshooting.

Technical Specifications

Parameter	Specification
Model	DMC 50720P-AC EXT 24 9032 0120 49
Power Supply	24VDC
Motor Type	AC Servo, Stepper, Hybrid Motors
Control Modes	Position, Velocity, Torque
Communication	Ethernet, CANopen, Modbus RTU
Digital Inputs	16 configurable inputs
Digital Outputs	12 configurable outputs
Analog Inputs	4 (0–10V / 4–20mA)
Analog Outputs	2 (0–10V / 4–20mA)
Operating Temperature	-20°C to +60°C
Protection	Overcurrent, overvoltage, thermal, motor stall
Dimensions (HxWxD)	160 x 80 x 50 mm
Weight	1.5 kg
Mounting	DIN rail or panel mount

Applications

The DMC 50720P-AC EXT 24 is suitable for:

Industrial robotics and automation systems
CNC machining centers
Packaging and material handling equipment
Conveyor and assembly lines
Laboratory and research automation
Motion control for hybrid machinery systems

Operation & Usage Instructions

Installation: Mount the module on a DIN rail or panel, ensuring proper grounding. Connect the 24VDC supply and motor outputs according to the wiring diagram.
Configuration: Use the front panel, software interface, or network commands to set motor type, encoder resolution, and motion profiles.
Operation: Start, stop, and control motion using programmable sequences, network commands, or external triggers.
Monitoring: Track motor position, velocity, torque, and module status via the built-in display or connected HMI/SCADA systems.
Maintenance: Review logged events, update firmware, and perform routine checks on connectors, cabling, and cooling conditions.

Technical Description

The DMC 50720P-AC EXT 24 integrates high-speed digital processing with precise analog feedback for optimal motor performance. Its modular design supports expansion with additional I/Os, making it adaptable to complex multi-axis systems. Advanced safety features and real-time diagnostics allow operators to maintain continuous operation while protecting motors and equipment from faults. The module’s network communication capabilities ensure integration into larger automation and control systems with minimal configuration.

Recommended IN MOTION Motion Control Modules

No.	Model	Power	Control Type
1	DMC 50710P-AC	24VDC	Single-axis AC Servo
2	DMC 50720P-AC	24VDC	Multi-axis AC Servo
3	DMC 50730P-DC	48VDC	DC Servo Control
4	DMC 50740P-AC	24VDC	High-speed Servo
5	DMC 50750P-DC	48VDC	Stepper Motor Control
6	DMC 50760P-AC	24VDC	Hybrid Motor Control
7	DMC 50770P-DC	48VDC	Multi-axis DC Servo
8	DMC 50780P-AC	24VDC	Linear Motor Control
9	DMC 50790P-DC	48VDC	CNC Servo Control
10	DMC 50800P-AC	24VDC	Robotic Motion Control
11	DMC 50810P-AC	24VDC	Interpolation Controller
12	DMC 50820P-DC	48VDC	Laboratory Automation
13	DMC 50830P-AC	24VDC	Multi-axis Parallel Control
14	DMC 50840P-DC	48VDC	High-precision Stepper Control
15	DMC 50850P-AC	24VDC	Industrial Automation Controller
16	DMC 50860P-DC	48VDC	Conveyor Motion Control
17	DMC 50870P-AC	24VDC	Packaging Line Controller
18	DMC 50880P-DC	48VDC	Assembly Line Motion Control
19	DMC 50890P-AC	24VDC	Remote Motion Controller
20	DMC 50900P-DC	48VDC	Multi-axis Synchronization
