The ABB SAO16D3AA358 is a specialized digital display unit designed for real-time process monitoring and status indication within industrial control panels. This module provides a clear, high-contrast interface for visualizing critical parameters, such as voltage, current, or frequency, directly from the field or via a centralized controller.
Technical Functionality
The SAO16D3AA358 functions as a dedicated signal converter and visualizer, translating analog or digital input data into a human-readable numeric format. Its robust electronic design ensures stable readings even in environments with high electromagnetic interference, making it ideal for power distribution and motor control centers.
Key Specifications
| Parameter | Specification |
| Model | SAO16D3AA358 |
| Display Type | High-visibility Digital Segment Display |
| Input Type | Configurable (Analog/Digital depending on firmware) |
| Mounting | Standard Panel Door / DIN-rail adapter |
| Supply Voltage | Rated for industrial DC or AC auxiliary power |
Operational Precautions
- Panel Sealing: When mounting on a cabinet door, ensure the protective gasket is correctly aligned to maintain the unit’s environmental ingress protection rating.
- Terminal Tightening: Use calibrated tools to tighten the rear screw terminals; over-tightening can damage the internal PCB traces, while loose connections may cause flickering.
- Ambient Temperature: Provide adequate ventilation if the unit is installed in a high-density rack, as excessive heat can reduce the lifespan of the display segments.
Common Questions Q&A
Q: Can the display range be calibrated manually? A: Yes, the SAO16D3AA358 typically features rear-mounted potentiometers or a software-defined menu for zero and span adjustment.
Q: Is this unit compatible with older ABB Advant systems? A: Compatibility depends on the specific interface card being used; however, as a standalone indicator, it can often be integrated into any system providing standard signal levels.
Recommended Similar Models
- SAO16D1: A basic version for single-parameter monitoring.
- SAO16D3BA: An upgraded variant with additional alarm relay outputs.
- DDU100: A high-density digital display unit for multi-channel tracking.
- SDI16: A specialized indicator for safety-instrumented systems.
- TPM100: A touch-sensitive version for more complex operator interactions.
Technical data and current availability for the ABB SAO16D3AA358 are available through our specialized automation inventory.
