The Allen-Bradley 1336S-B010-AA-EN6-HA1 is a high-performance AC Drive from the renowned 1336 PLUS series. Engineered by Rockwell Automation, this Sensorless Vector drive is designed to provide exceptional motor control for demanding industrial applications. It combines powerful performance with a user-friendly Human Interface Module (HIM) to ensure seamless integration into existing automation frameworks.



Product Datasheet & Technical Specifications

This drive is built for precision and durability. Below are the core technical parameters for the 1336S-B010-AA-EN6-HA1:

• Input Voltage: 380-480V AC (3-Phase)
• Horsepower Rating: 10 HP (7.5 kW)
• Output Current: Approximately 15 Amps
• Enclosure Rating: IP20 (NEMA Type 1)
• Control Method: Sensorless Vector Control for high torque at low speeds
• Human Interface Module (HIM): Analog Potentiometer (HA1) included for local speed control
• Language Package: English (EN6)
• Frequency Range: 0 to 400 Hz output



Country of Origin

This product is primarily manufactured in the United States (USA), reflecting Rockwell Automation’s commitment to high-quality industrial standards and rigorous testing.



Application Fields

The 1336 PLUS series is versatile and found in numerous sectors:

• Conveyor Systems: Managing precise speed for material handling.
• HVAC Systems: Controlling fans and centrifugal pumps for energy efficiency.
• Extruders: Providing steady torque for plastic and rubber manufacturing.
• Mixers and Agitators: Handling varying loads with sensorless vector precision.
• Machine Tools: Managing spindle speeds in metalworking.

Product Instructions & Technical Notes

When installing the 1336S-B010-AA-EN6-HA1, ensure the environment is free from conductive dust and corrosive vapors. The drive utilizes a digital programming interface, allowing users to tune motor parameters such as acceleration/deceleration times and overload protection. Always ensure proper grounding to the “PE” terminal to prevent electromagnetic interference (EMI). The HA1 interface allows for immediate manual adjustments, which is ideal for testing and commissioning phases.



Q&A – Frequently Asked Questions

Q1: What does “Sensorless Vector” mean for this drive? A: It means the drive can estimate the motor’s position and speed based on current and voltage feedback without requiring an external encoder, providing high torque even at low RPM.

Q2: Can I use this drive for a 230V motor? A: No, this specific model is designed for 460V (B-code) input and output. Using it with lower voltage motors may cause damage or improper operation.

Q3: Is the HIM module removable? A: Yes, the HA1 module can be removed or replaced, but it is essential for local manual control and parameter viewing.

Q4: Does this drive support communication protocols? A: While this base model focuses on local control, the 1336 series can be fitted with communication cards for RIO, DeviceNet, or EtherNet/IP.



Similar Model Recommendations

If you are looking for alternatives or supplementary units for the Allen-Bradley 1336S-B010-AA-EN6-HA1, consider these models:

1. Allen-Bradley 1336S-B015-AA-EN6-HA1 (15HP version)
2. Allen-Bradley 1336S-B007-AA-EN6-HA1 (7.5HP version)
3. Allen-Bradley 1336F-B010-AA-EN (Plus II series alternative)
4. Allen-Bradley 20F11NC015AA0NNNNN (Modern PowerFlex 753 equivalent)
5. Allen-Bradley 1336S-BRF50-AA-EN6 (Small fractional HP version)
