The GEC Alsthom MCND0412KHB2552 is a specialized industrial protection relay within the MCND series. This series is primarily designed for high-performance directional control and phase-fault protection in medium to high-voltage electrical networks. The MCND series utilizes static (solid-state) technology to provide faster response times and higher precision compared to traditional electromechanical relays, ensuring the stability of the power grid by isolating faulty sections rapidly.

Product Parameters and Technical Specifications

This relay is built to meet the demanding requirements of utility-grade protection schemes.

• Model Number: MCND0412KHB2552
• Series: MCND (Directional Comparison/Phase Protection)
• Configuration: 4-Pole / Multi-element design (indicated by the “04” prefix)
• Rated Current (In​): Typically 1A or 5A AC (Standard CT secondary)
• Rated Frequency: 50/60 Hz
• Auxiliary Voltage: 110-125V DC (Common for KHB suffix, though must be verified against the unit nameplate)
• Case Size: Modular M-series case for rack or flush mounting
• Contacts: Heavy-duty silver-alloy contacts for breaker tripping and alarm signaling



Product Datasheet Summary

The MCND0412KHB2552 datasheet highlights its use of sensitive directional elements. The “KHB” designation in the model string typically refers to the specific combination of measurement elements and the characteristic angle used for fault detection. The relay features a draw-out construction, allowing the internal circuitry to be removed from the outer case for testing without disturbing the current transformer (CT) shorting links or external wiring. It is designed with high electromagnetic compatibility (EMC) to operate reliably in the electrically noisy environment of a high-voltage substation.



Country of Origin

This protection relay was manufactured in the United Kingdom, at the specialized GEC Alsthom protection and control facility in Stafford.



Application Fields

The MCND series is essential for complex distribution and transmission protection:

• Directional Overcurrent Protection: Used in looped or parallel feeders where non-directional relays would cause unnecessary trips.
• Transformer Protection: Providing backup phase-fault protection for large power transformers.
• Industrial Substations: Protecting critical busbars and high-capacity industrial feeders.
• Interconnector Lines: Ensuring fault current is only interrupted when it flows in a specific direction relative to the protected zone.



Product Usage Instructions

1. Unpacking and Inspection: Check the relay module for any signs of mechanical damage. Ensure the flag indicators move freely.
2. Mounting: Secure the case into the panel. When inserting the relay module into the case, ensure the guide rails are aligned to prevent damage to the rear connector pins.
3. Commissioning: Before energizing, verify that the auxiliary DC supply matches the relay’s rating. Perform a secondary injection test to confirm the pickup thresholds and directional sensitivity.
4. Maintenance: Periodically check the diagnostic LEDs (if equipped) and the mechanical targets. No routine internal cleaning is required due to the sealed case design.



Technical Description

The MCND0412KHB2552 operates by comparing the phase relationship between the measured current and a reference voltage (polarizing voltage). This allows the relay to determine the direction of the fault power flow. The internal static circuitry processes the analog inputs through precision filters to eliminate harmonics that could cause false tripping. The definite-time or inverse-time characteristics are determined by the internal logic, which is stable across a wide temperature range, ensuring consistent coordination with other protection devices in the system.



Q&A – Frequently Asked Questions

Q: What does the “Static” designation mean for this relay? A: It means the logic and measurement functions are performed by electronic components (transistors, integrated circuits) rather than moving parts like induction discs. This results in a much lower “burden” on the system’s instrument transformers.

Q: Can the MCND relay be tested while the system is live? A: Yes, provided the case is equipped with an MMLG test block. This allows the CT circuits to be safely shorted and the trip circuits isolated while test signals are injected.

Q: How does the directional feature work? A: The relay uses a “quadrature” connection or similar method to compare the current in one phase with the voltage of the other phases to establish a reference plane for fault detection.

Q: Where can I find more GEC Alsthom MCND series components? A: You can source the GEC Alsthom MCND0412KHB2552 and other legacy protection modules through specialized industrial automation and power grid equipment suppliers.



Recommended Similar Models

1. GEC Alsthom MCND01 – Single-pole version for specific phase-fault applications.
2. GEC Alsthom METI – Legacy directional relay often found in the same panels as MCND units.
3. GEC Alsthom MCGG – Non-directional overcurrent relay commonly used as a primary or backup companion.
4. Alstom MiCOM P127 – The modern numerical equivalent for directional overcurrent protection.
5. GEC Alsthom MCAA – Standard auxiliary relay used for expanding the contact output of the MCND series.
